Product Highlights
| Contact Angle 110o max | Comply with RoHS Environmental Directive | Comply with REACH Environmental Directive |
| Suitable for Various Attachment Processes | Waterproof, Moisture-Proof and Corrosion-Resistant | Reduce Dust Adhesion |
| Wear Resistance | Does Not Affect Electrical Performance | Strong Adhesion |
Product Features
- Can be used as a primer on unchromized light metals.
- Has good corrosion resistance and oxidation resistance.
- Anti-dust adhesion, easy to clean, scratch-resistant, hardness 5~8H (different substrates).
- Can be dyed with inorganic paint.
- Has high temperature protection and temperature mutation protection.
- Thin film coating (5μm~15μm), effective cost saving.
- Highly hydrophobic and oleophobic properties (contact angle 110o max).
- The heat dissipation efficiency of the radiator surface is increased by 5-20% and dust is not easy to accumulate.
- The attachment process is simple, such as spraying, dipping, etc.
Industry Applications
 |  |  |  |  |
| Water Proof | Anti-Fingerprint | Highly Hydrophobic | Self-Cleaning | Antifouling |
Performance Indicators KEY-115A?
Material | Pencil Hardness Test | Wear Resistance Test | Impact Resistance Test | Cupping test | Plate thickness 70*150MM | Specification |
Magnesium | 4H 5H | After 100 Times, The Board Is Not Exposed | No Abnormality | No Abnormality | 0.9 2 | AZ31 AZ91 |
Aluminum | 2H 4H | After 100 Times, The Board Is Not Exposed | No Abnormality | No Abnormality | 0.5 0.8 | A1050P A5052P |
Titanium | 9H | After 100 Times, The Board Is Not Exposed | No Abnormality | No Abnormality | 0.8 | TP340C |
Stainless Steel | 4H | After 100 Times, The Board Is Not Exposed | No Abnormality | No Abnormality | 0.8 | SUS304 |
Copper | 4H | After 100 Times, The Board Is Not Exposed | No Abnormality | No Abnormality | 0.8 | C1100P |
Brass | 3H | After 100 Times, The Board Is Not Exposed | No Abnormality | No Abnormality | 0.8 | C2801P |
Please Note
Use: It can be used right after opening the can, without dilution. When impregnated, it can cover about 60-75 m2/kg (at a thickness of 5-15μm).
Operating environment 0℃~35℃.
Lifespan: More than 10 years (theoretical lifespan is 25-30 years. The coating examples so far have lasted for 10 years without any problems).
Packing Specifications
5KG、10KG、15KG、25KG
Storage and Transportation Requirements
Transport as non-hazardous chemicals and non-corrosive chemicals.
Storage temperature -10 to +25°C
Keep sealed, avoid direct sunlight and high heat.
Sealed warranty: 12 months.
